BJ5182ZXXE6-P1 Roll-off Garbage Truck

BJ5182ZXXE6-P1 Roll-off Garbage Truck

BJ5182ZXXE6-P1 Roll-off garbage truck also known as hook arm truck, pull arm hook; Can be equipped with a number of truck, with self-unloading function, hydraulic operation, convenient dumping, simple operation, suitable for towns, streets, industrial and mining enterprises, residential towns bagging, bulk household garbage collection, transfer operations of special vehicles.

The truck can pull the garbage in the garbage box and the garbage box together to the car to carry away, but also can be self-unloading operation, reduce the labor intensity of workers. The collection and transportation mode of the garbage truck is widely used in the world at present??greatly reducing the cost and space of the equipment. The functions of the special device are powered by the automobile engine, which is realized manually or electronically by the hydraulic mechanism. The truck body adopts high quality carbon steel plate completely sealed welding structure, which has the advantages of high strength, light weight and no secondary pollution.

SKU: BJ5182ZXXE6-P1 Category:
  • The truck electronic control system adopts the integrated design of electronic control system.
  • WeiChai power /WP4.6NQ220E61 diesel engine, rated power of 162 kW, rated speed of 2300 RPM, emissions meet the national VI standards, strong power, low noise, more fuel efficient, stable and reliable performance.
  • The hydraulic pipe adopts the international general DIN24 ?? standard, the hydraulic pipe adopts galvanized precision seamless steel pipe, the use of Eton Walform extrusion molding, CNC bending molding, the use of three-stage filtration system, to ensure the cleanliness of the hydraulic system above NAS9 level.
  • Foton new supertruck chassis: European technical standards of production, bearing capacity, low fuel consumption, low noise, smooth driving, for the garbage truck design of the special chassis.
Truck Model:BJ5182ZXXE6-P1
Total Mass:18000 kg
Rated Load:10570 kg
System Pressure:30 MPa
Power:162 kW
Wheelbase:4500 mm
Basic Turck(L * W * H):7300 mm * 2530 mm * 3080 mm
Top Speed:90 km/h
Displacement:4580 ml
Tire Specifications:10.00R20
Max. Approach Angle:19 ??
Max. Departure Angle:16 ??
Lead Time:15-30 Working Days
Payment Terms:T/T ,L/C

Foton BJ5182ZXXE6-P1 Roll-off Garbage Truck Data Sheet

ModelBJ5182ZXXE6-P1Total Weight 18000 kgEquipment Weight7300 kg
Rated Load 10570 kgTruck Length 7300 mmTruck Width 2530 mm
Truck Height 3080 mmMax. Approach Angle 19 ??Max. Departure Angle 16 ??

Chassis Argument of Foton BJ5182ZXXE6-P1 Roll-off Garbage Truck

Model Specifications BJ1184VKPFN-01Wheelbase 4500 mmNumber of Axes2
Top Speed 90 km/hTire Quantity6Tire Specifications10.00R20
Engine ModelWP4.6NQ220E61Displacement 4580 mlPower 162 kW
????END????



Foton BJ5182ZXXE6-P1 Roll-off Garbage Truck Bodywork Parameter

Outside Width of Truck Body Track1060 mmDistance from Hook Arm to Rear Axle Center4100 mm
Car Body Track Clearance Height??115 mmMatch the Car Body Size12 m3
System Pressure30 MPaLifting Capacity14 TTipper Tilt Angle49 ??
Height of Hook Arm1570 mmSelf-Unloading Time??60 sLoading and Unloading Time??60 s
????END????
