BJ5182ZYSE6-P1 Compressed Garbage Truck

BJ5182ZYSE6-P1 Compressed Garbage Truck

BJ5182ZYSE6-P1 compressed garbage truck is a rear-loading compression type, which is a new generation of rear-loading compressed garbage truck independently developed and designed by Environmental Equipment Company on the basis of absorbing the advantages of a variety of similar products at home and abroad. The truck is beautiful in appearance, excellent in performance, advanced in operation and control. It adopts rear loading compression and bidirectional compression technology to complete the collection and transfer of urban household garbage. It has strong loading capacity and large loading capacity, and its comprehensive performance has reached the advanced level of similar domestic products. The chassis adopts the Foton class 2 automobile special chassis, excellent quality, strong engine power, emissions to meet the national VI standards, mainly suitable for urban residential areas, communities, large factories and mines and institutions in buckets, bags and bulk household garbage collection and transportation, a variety of bucket (bucket) institutions, suitable for different users of a variety of garbage collection.

SKU: BJ5182ZYSE6-P1 Category:
  • Foton new generation of sanitation chassis: European technical standards of production, bearing capacity, low fuel consumption, low noise, smooth driving, for the compression garbage truck design of the special chassis.
  • Adopts Weichai WP4.6NQ220E61 diesel engine, rated power 162 kW, strong power, low noise, more fuel efficient, stable and reliable performance.
  • Truck electric control system adopts on-board control system (CAN line), which can realize the integration of electric control system (one-button control).
  • The hydraulic pipe adopts the international general DIN24?? standard, the hydraulic pipe adopts galvanized precision seamless steel pipe, the use of Eton Walform extrusion molding, CNC bending molding, the use of three-stage filtration system, to ensure the cleanliness of the hydraulic system above NAS9 level.
  • According to different user needs, can choose to install tipping bucket, tipping bucket and Lifting bucket three kinds of packing mechanism.
Truck Model:BJ5182ZYSE6-P1
Total Mass:18000 kg
Rated Load:6905/6970/6735/6800 kg
Hydraulic System Pressure:16 MPa
Push-Shovel Back Pressure:12 MPa
Wheelbase:4500 mm
Basic Turck(L * W * H):9050/8650 mm * 2490 mm* 3365/3265 mm
Top Speed:90 km/h
Filler Volume:1.5 m3
Sewage Tank Volume:0.94 m3
Max. Approach Angle:19 ??
Max. Departure Angle:13 ??
Lead Time:15-30 Working Days
Payment Terms:T/T ,L/C

Foton BJ5182ZYSE6-P1 Compressed Garbage Truck Data Sheet

ModelBJ5182ZYSE6-P1Total Weight 18000 kgEquipment Weight 10900/11070 kg
Rated Load 6905/6970/6735/6800 kgTruck Length 9050/8650 mmTruck Width 2490 mm
Truck Height 3365/3265 mmMax. Approach Angle 19 ??Max. Departure Angle 13 ??

Chassis Argument of Foton BJ5182ZYSE6-P1 Compressed Garbage Truck

Model SpecificationsBJ1184VKPFN-01Wheelbase 4500 mmNumber of Axes2
Top Speed90Tire Quantity6Tire Specifications10.00R20
Engine ModelWP4.6NQ220E61Displacement 4580 mlPower 162 kW
????END????

Foton BJ5122ZYSE6-H1 Compressed Garbage Truck Bodywork Parameter

Filling Device One Working Cycle Time??25 sUnloading Device One Working Cycle Time??45 s
Feeding form/Capacity(240/660)/1.5 L/m3Effective Volume of Dustbin10 m3
Hydraulic System Pressure16 MPaPush-Shovel Back Pressure12 MPa
Compression MethodBidirectionalFiller Volume1.5 m3Sewage Tank Volume0.84 m3
Full Cleaning13.28 L/h ; 4.28 L/10000 ?ODeep Cleaning11.18 L/h ; 3.61 L/10000 ?O
????END????

Optional Accessories of Foton BJ5122ZYSE6-H1 Compressed Garbage Truck

1. Weighing System2. Double Waste Water Tank3. Reversing Camera
4. Wireless Remote Control5. Video Record and Video Burning6. Sewage Suction Systems
7. 360
????END????
