BRIEF
This Foton runway vacuum sweeper truck is fitted with reliable Foton Cummins power unit and right-hand drive layout, specially developed for airport runway, airport apron and large port road cleaning work. Integrated with high-power vacuum air suction system and side sweeping brushes, it achieves thorough removal of gravel, debris, dust and rubber residues without secondary dust scattering. The whole vehicle features solid construction, stable driving performance and excellent dust filtering capacity, adapting to long-hour continuous operation under heavy-duty scenarios. Equipped with mature chassis and powerful Cummins engine, the vehicle delivers strong power output and easy manipulation. Customizable body color and stable all-round performance make it the ideal cleaning equipment for airports, container terminals, large logistics ports and wide industrial pavements.
Parameters
| Vehicle model | AUMARK-C33 | |
| Cabin | Single row/W1995/right rudder | |
| Whole vehicle main dimensions | Overall dimensions (LxWxH)mm | 5875×2030×2230 |
| Wheel base(mm) | 3360 | |
| Weight data | Curb weight(kg) | 2600 |
| Gross vehicle weight(kg) | 6495 | |
| Persons in cab | 3 | |
| Whole vehicle main performance | Max. speed(km/h) | 95 |
| ENGINE | Model | F3.8s3141 |
| Emissions standards | Euro 3 | |
| Displacement(L) | 3.76 | |
| Rated Power(kw/rpm) | 105 | |
| Max torque (N.m/rpm) | 450 | |
| Gearbox | Model | 6TS55 |
| Front axle | Type/Mainreducetion ratio | 2.2T |
| Rear axle | Type/Mainreducetion ratio | 5.5T/4.11 |
| Suspension | Front suspension/Leaf spring number | 3+1 |
| Rear suspension/Leaf spring number | 6+7 | |
| Brake system | Service brake | Drum pneumatic braking |
| Parking brake | Central drum brake | |
| Auxiliary brake | Engine exhaust brake | |
| Wheels and tyre size | 6+1(7.00R16) | |
| Vehicle model | AUMARK-C38 | |
| Cabin | Single row/W1995/right rudder | |
| Whole vehicle main dimensions | Overall dimensions (LxWxH)mm | 6725×2100×2280 |
| Wheel base(mm) | 3800 | |
| Weight data | Curb weight(kg) | 3305 |
| Gross vehicle weight(kg) | 6500 | |
| Persons in cab | 3 | |
| Whole vehicle main performance | Max. speed(km/h) | 95 |
| ENGINE | Model | F3.8s3141 |
| Emissions standards | Euro 3 | |
| Displacement(L) | 3.76 | |
| Rated Power(kw/rpm) | 105 | |
| Max torque (N.m/rpm) | 450 | |
| Gearbox | Model | 6TS55 |
| Front axle | Type/Mainreducetion ratio | 2.5T |
| Rear axle | Type/Mainreducetion ratio | 6.0T/4.875 |
| Suspension | Front suspension/Leaf spring number | 9 |
| Rear suspension/Leaf spring number | 11+7 | |
| Brake system | Service brake | Drum pneumatic braking |
| Parking brake | Brake gas brake | |
| Auxiliary brake | Engine exhaust brake | |
| Wheels and tyre size | 6+1(8.25R16) | |
| Tanks | volume | Water tank volume: 1.5 square dustbin volume: 4 square |
| Box body material | Material of tank: stainless steel Dash material: stainless steel | |
| Sub-engine brand and power | I suzu Engine Co. Ltd | |
| Cleaning the width | 2.8-3.0m | |
| Operation ability | 38000(m2/h) | |
| Cleaning speed (km/h) | 15-20 | |
| Cleaning speed (km/h) | 3-15 | |
| Suction capacity | Density (g/cm3) : 2.0 mass (kg) : 1.5 suction particle size (mm) : ≥100 | |
| Garbage box tipping Angle | ≥45° | |
| Cleaning efficiency | ≥96% | |
| The fan system | Special high pressure centrifugal fan, desktop fan (maintenance free) rated working speed 2700r/min | |
| Suction nozzle device | The suction nozzle is suspended between the rear wheels of the chassis car, which is composed of a suction nozzle, a roller and a straw. The suction nozzle body can be moved along with the suction nozzle, and the suction nozzle lifting oil cylinder is controlled. | |
| Scanning plate Angle adjustment | Forward scanning plate: forward 5°~15° outward 5°~10° rear scanning plate: forward 5°~10° inward 5°~10 | |
| Single sweep plate with the number of brushes | 22 | |
| Vice frame | Vice beam at the tank bottom | Q345 carbon steel plate |
