Foton Guardrail Cleaning Truck for Urban Maintenance

BRIEF

This Foton Urban Guardrail Cleaning Truck is professionally customized for the regular maintenance and washing of urban road isolation guardrails and anti-glare barriers. It stands out with prominent advantages of low fuel consumption, low running noise, easy operation, comprehensive integrated functions and agile mobility, adopting domestically leading core cleaning technology to serve as an ideal sanitation vehicle for municipal road maintenance.

The vehicle is equipped with two groups of four round brushes supporting 0–45° integral angle adjustment, enabling both horizontal and vertical scrubbing against guardrails. Its rubber-nylon blended brush filaments deliver balanced elasticity and toughness, which can deeply reach the vertical surfaces of anti-glare guardrails—effectively fixing the long-standing cleaning blind spot that vertical roller or disc brushes fail to tackle. Paired with auxiliary high-pressure water guns for flushing the bottom of guardrail beams, this machine achieves superior cleaning cleanliness and working efficiency without scratching or damaging the guardrail paint finish.

Core Key Parameters

1. Vehicle Basic Info Brand: Brock, Model BJ5084GQXE6-P3; GVW 8275kg, Overall Dimension 5995×2160×2475mm, Wheelbase 3360mm, Tire 7.50R16
2. Power Configuration Main engine optional 115kW / 125kW; Auxiliary engine: YUNNEI T4
3. Water Tank & Pressure Max effective water tank volume 3.6m³, water spray pressure 4MPa
4. Guardrail Cleaning Performance 4 roller brushes, brush rotating speed 800–1200r/min, brush adjustable angle 0–45°, working speed 2–10km/h; Cleaning height range 120–1500mm, cleaning thickness 0–220mm
5. Cleaning Mechanism Adjustment Unit vertical adjustment ≥100mm, maximum outward extension ≥500mm, lateral adjustment ≥100mm, inner & outer scrubbing spacing adjustable by 500mm
6. Chassis Model: BJ1088VEJEA-FK

Main structural features
1. roller brush can be rotated 0-45 degrees angle, the operator can according to the different guardrail change the angle of scrubbing.
2.Operation is flexible and simple, the control switch is centrally installed in the cab, and all electric control operations can be completed in the cab equipped with heating and cooling air conditioning.
All electric control operations can be completed in the driver’s cab equipped with warm and cold air-conditioning.
3.Second level speed reducer, operating speed 2-10km/h arbitrary control.
4.The roller brush can be lifted and lowered hydraulically, and adjusted in and out, change angle and tilt.
5.Equipped with air blowback system to prevent the water pump and pipeline from freezing in winter.
6.Hydraulic and electronic components are international and domestic famous brands, reliable performance.
7. the water tank is made of stainless steel plate, large volume (total volume of 3.5 cubic meters), can ensure that the continuous work on the road for more than 3.5 hours.
More than 3.5 hours of continuous work on the road.
8.Sub-engine(Yunnai T4) is rear-mounted, which is convenient for overhauling and heat dissipation.
9.the installation of hydraulic oil pump to drive the new piston diaphragm water pump can simultaneously provide water for rolling brush and rinse water gun water, can simultaneously carry out brushing operations or washing traffic
Brushing operations or washing traffic signs, traffic signs, billboards and so on.
10.Hydraulic system is electromagnetic hydraulic valve group, easy maintenance, convenient function expansion.
11.cleaning brush and guardrail plate surface automatically maintain a constant distance, according to the wear and tear of the bristles can be freely adjusted to ensure the quality of cleaning, efficiency and safety, cost savings.
Ensure the quality, efficiency and safety of cleaning, and save the cost.
