BJ5075ZZZE6-P2 Rear Loader Garbage Truck

BJ5075ZZZE6-P2 self handling garbage truck is a collection, transfer to clean up the transportation of garbage, to avoid secondary pollution of new sanitation trucks, its main characteristics are simple garbage collection, efficient, good environmental protection, vehicle utilization efficiency is high, widely used in sanitation, municipal, property community, garbage and concentrated residential areas, urban street garbage treatment, All have sealing self-discharging function, hydraulic operation, easy to dump garbage.
Self handing garbage truck adopts Foton special vehicle chassis, plus garbage box, connecting accessories, guardrail and hydraulic system and other devices. It has the characteristics of safe operation, stable performance, low repair rate, timely and thoughtful after-sales service. This product is mainly used for the collection and transfer of urban residential areas, township streets and other household waste. The vehicle is small and flexible, easy to move, suitable for crowded commercial areas and poor road traffic in urban and rural areas. The car is equipped with a rear hanging bucket feeding mechanism, which can operate at the tip of the bucket, and can butt with 120 L/240 L/660 L standard plastic bucket. The vehicle has the function of self-unloading, convenient discharging.

SKU: BJ5075ZZZE6-P2 Category:
  • The structure is strong and corrosion-resistant ship box structure to achieve 100 % no leakage; Scraper feed + compression high compression efficiency.
  • Good engine dynamic control economy; The hydraulic system is stable and reliable; High degree of electrical automation, electro-hydraulic joint control.
  • The chassis is BJ1078VEJDA-AB2 truck special chassis, strong bearing capacity, low fuel consumption, low noise, smooth driving.
  • The engine adopts all-diesel Q28-130E60 diesel engine, which meets the national VI emission standard with rated power of 96 kW and speed of 2500 RPM.
Truck Model:BJ5075ZZZE6-P2
Total Mass:7360 kg
Rated Load:745 kg
Max. Approach Angle:20 ??
Max. Departure Angle:15 ??
Wheelbase:N/A
Basic Turck(L * W * H):6060 mm * 2080 mm * 2480 mm
Number of Axes:N/A
Top Speed:N/A
Displacement:N/A
Power:96/2500 kW
Tire Quantity:N/A
Lead Time:15-30 Working Days
Payment Terms:T/T ,L/C

Foton BJ5075ZZZE6-P2 Rear Loader Garbage Truck Data Sheet

ModelBJ5075ZZZE6-P2Total Weight 7360 kgEquipment Weight 4780 kg
Rated Load 2450 kgTruck Length 6060 mmTruck Width 2080 mm
Truck Height 2480 mmMax. Approach Angle 20 ??Max. Departure Angle 15 ??

Chassis Argument of Foton BJ5075ZZZE6-P2 Rear Loader Garbage Truck

Model SpecificationsBJ1078VEJDA-AB2Wheelbase (mm)N/ANumber of AxesN/A
Top Speed (km/h)N/ATire QuantityN/ATire SpecificationsN/A
Engine ModelQ28-130E60Displacement (ml)N/APower 96/2500 kW
????END????

Foton BJ5075ZZZE6-P2 Rear Loader Garbage Truck Bodywork Parameter

Effective Volume of Dustbin7 m3Self-Unloading Maximum Discharge Angle (??)N/A
Dustbin Unloading Angle88??2 ??Garbage Bin Discharge Angle??45 ??
Cycle Time of Feeding Operation??25 sWorking Time Working Speed1200 RPM
Cycle Time for Unloading Operation??40 sCycle Time of Compression and Filling Operation??60 s
????END????
