BJ5082ZZZE6-P1 Side Loader Garbage Truck

BJ5082ZZZE6-P1 Side Loader Garbage Truck

BJ5082ZZZE6-P1 self handling garbage truck is a new generation of self-handling garbage truck independently developed and designed by Foton Broko Environmental Equipment Co., LTD. The truck has beautiful appearance, excellent performance and perfect control. The chassis adopts Beiqi Foton type truck chassis modification, excellent quality, strong engine power, emissions meet the prescribed emission standards. It is mainly used for the collection and transportation of barrels of household garbage in urban residential areas, communities and institutions.

SKU: BJ5082ZZZE6-P1 Category:
  • Adopt Aoling new Rapid transit special vehicle chassis of the second class, this vehicle adopts riveted frame, strong bearing capacity.
  • Kunming Yunnei Power Co., LTD. D30TCIF1 National VI power diesel engine, rated power 125 kW, emissions meet the national standard.
  • The hydraulic system matches the brand oil pump and hydraulic cylinder, and the gear pump is driven by the manual force extractor.
  • The shovelling is welded with high-quality structural steel. It is a part for discharging products. The shovelling is arranged inside the dustbin and slides along the track of the dustbin driven by the hydraulic cylinder to complete the discharging operation. Compression discharge two ?C in ?C one pushing plate system, can achieve compression function.
  • The rear door is sealed with silicone rubber at the joint surface of the dustbin, and the double oil cylinder can be mediated and locked to effectively prevent sewage dripping and reduce environmental pollution.
Truck Model:BJ5082ZZZE6-P1
Total Mass:8275 kg
Rated Load:2745 kg
Max. Approach Angle:20 ??
Max. Departure Angle:18 ??
Wheelbase:3360 mm
Basic Turck(L * W * H):5890 mm * 2285 mm * 2690 mm
Number of Axes:2
Top Speed:105 km/h
Displacement:2977 ml
Power:125 kW
Tire Quantity:6
Lead Time:15-30 Working Days
Payment Terms:T/T ,L/C

Foton Brock  BJ5082ZZZE6-P1 Side Loader Garbage Truck

ModelBJ5082ZZZE6-P1Total Weight 8275 kgEquipment Weight 5400 kg
Rated Load 2745 kgTruck Length 5890 mmTruck Width 2285 mm
Truck Height 2690 mmMax. Approach Angle 20 ??Max. Departure Angle 18 ??

Chassis Argument of Foton Brock  BJ5082ZZZE6-P1 Side Loader Garbage Truck

Model SpecificationsBJ1088VEJEA-FKWheelbase 3360 mmNumber of Axes2
Top Speed 105 km/hTire Quantity6Tire Specifications7.50R16
Engine ModelD30TCIF1Displacement 2977 mlPower 125 kW
????END????

Foton Brock  BJ5082ZZZE6-P1 Side Loader Garbage Truck Bodywork Parameter

Filling Device One Working Cycle Time ??25 sUnloading Device One Working Cycle Time ??80 s
Effective Volume of Dustbin 8 m3
????END????

Optional Accessories of Foton Brock  BJ5082ZZZE6-P1 Side Loader Garbage Truck

1. Reversing Camera2. Wireless Remote Control3. Reversing Radar
????END????
