Foton 25 CBM Water Sprinkler Truck

BRIEF

This Foton 25 CBM Water Sprinkler Truck is a heavy-duty municipal sanitation vehicle built on the reliable Foton Auman chassis, engineered for large-volume water transportation and multi-scene spraying operations. Designed for urban greening, road dust suppression, construction site watering, fire emergency auxiliary work and farmland irrigation, this water sprinkler truck delivers stable and powerful spraying performance for long-duration field tasks.

Equipped with CRRC integrated superstructure, the vehicle adopts a robust Weichai 270HP Euro 6 diesel engine to provide abundant, steady power output. The matched specialized sprinkler pump serves as the core working component, featuring outstanding water delivery efficiency and strong suction capacity. Users can freely adjust the horizontal rotation and spray angle of the water cannon to meet different operational requirements. It boasts long water throw distance and wide coverage area, enabling fast and uniform spraying across extensive zones.

The water tank is constructed with thick Q235B carbon steel, ensuring excellent structural strength and anti-leakage performance for long-term service. The tank comes with a top manhole for convenient inspection, cleaning and maintenance of the inner cavity. The whole sprinkling system integrates multiple spray outlets including front, rear and side sprinklers, supporting diverse working modes such as watering, mist spraying and long-distance water cannon jetting.

The truck adopts a row-and-half left-hand drive cabin with power-assisted steering and pneumatic brake system, bringing comfortable and safe driving experience for operators. The multi-speed manual gearbox realizes flexible speed control to adapt to complex road conditions like urban streets, industrial zones and construction sites. With high working efficiency and adjustable spray speed, this Foton water sprinkler truck is an ideal heavy-duty sanitation solution for large-scale water distribution and dust control projects.

 Product Features

1. Built on mature Foton Auman heavy-duty chassis for stable driving performance.
2. Vehicle model CRRC/WS25BJ270L6 with integrated professional superstructure.
3. Powered by Weichai 270HP Euro 6 diesel engine with strong power reserve.
4. Fitted with specialized sprinkler pump as core working assembly.
5. 25 CBM large-capacity water tank for long continuous operation.
6. Tank made of 5mm Q235B carbon steel for great durability.
7. Equipped with top manhole for easy tank inspection and cleaning.
8. Supports horizontal rotation and adjustable spray angle of water cannon.
9. Features long water throw range and wide sprinkling coverage.
10. Fast water suction speed, filling the tank within short time.
11. Multi-direction sprinkling outlets: front, rear and side sprinklers.
12. Row-and-half LHD cabin with comfortable operating space.
13. 9-forward & 1-reverse gearbox for flexible speed regulation.
14. Pneumatic brake system ensures reliable braking safety.
15. Power-assisted steering reduces driver operation fatigue.
16. 10 main tires plus one spare tire for heavy load travel.
17. Supports multiple working modes: watering, dust suppression, fire aid.
18. Comes with complete accessories: self-flow valve, fire joint and water pipes.
19. High pump efficiency to cut energy consumption during operation.
20. Suitable for municipal, construction, agriculture and emergency scenarios.
