Foton 4CBM Low Noise Quiet Road Sweeper Truck

BRIEF

This CRRC RS4BJ95L6 low noise road sweeper truck is built on mature Foton Forland chassis, engineered as a compact sanitation vehicle for quiet and efficient urban cleaning. Powered by Quanchai 95HP Euro 6 diesel engine, it adopts auxiliary engine and blower as its core working assemblies, delivering reliable sweeping performance with ultra low noise operation, ideal for noise-sensitive working zones such as parks, school roads, residential districts and airports.

The low noise quiet road sweeper truck integrates sweeping, garbage collection and waste transportation into one machine. It is equipped with advanced dust removal technology with three-stage dust removal structure to avoid secondary pollution. The high-performance centrifugal blower features strong suction and quiet running; paired with side tilting brushes and long suction cup, it sweeps debris and sucks waste into the 4 cubic meter trash bin smoothly in closed-loop airflow. The durable hydraulic system controls brush lifting, suction nozzle movement and bin tipping, supported by solenoid valve assembly for stable hydraulic drive.

It comes with an integrated control system with centralized cabin control panel, enabling operators to monitor working status in real time. A manual pump emergency system is reserved, which can lift the garbage bin even when the auxiliary engine stops, greatly simplifying maintenance work. The suction nozzle adopts hydraulic floating design to extend service life, and the filter cylinder is easy to disassemble and clean to prevent clogging. This versatile low-noise road sweeper fits municipal roads, factories, mines, highways and piers, offering clean, quiet and eco-friendly road maintenance solution for sanitation contractors and government departments.

Product Features

1. CRRC RS4BJ95L6 low noise quiet road sweeper mounted on Foton Forland chassis
2. Powered by Quanchai 95HP Euro 6 diesel engine for low emission performance
3. Auxiliary engine and blower set as the core working components
4. Ultra low noise operation suitable for residential areas, parks and schools
5. 4 cubic meters garbage bin capacity for storing collected road waste
6. Advanced three-stage dust removal system to eliminate secondary pollution
7. High wear-resistant centrifugal blower with strong suction and simple maintenance
8. Side tilting brushes cooperate with long suction cup to collect debris efficiently
9. Durable hydraulic design controls brush, suction nozzle and bin tipping actions
10. Solenoid valve assembly ensures stable hydraulic drive for all sweeping movements
11. Integrated cabin control panel with real-time working status monitoring
12. Manual pump emergency system supports bin lifting when auxiliary engine fails
13. Hydraulic floating suction nozzle protects rubber wheel and extends service life
14. Inclined plate trash bin structure for smooth, automatic waste discharging
15. Air pulse filter cylinder cleaning device prevents filter clogging effectively
16. Compact vehicle size, flexible for narrow urban roads and small sites
17. Combine suction and sweeping function, dry operation available
18. Widely applicable for airport, pier, factory, highway and municipal road cleaning
19. Easy disassembly of filter cylinder for convenient daily inspection and maintenance
20. Eco-friendly sanitation equipment to keep urban environment clean and tidy

Specification

Vehicle Technical Specifications
Size	5150×1760×2280mm
GVW/Curb Weight	4495kg/3850kg
Rated weight	515
Wheelbase	2600mm
Number of tires	6
Tire specifications	6.00R15 10PR
Number of axes	2
Approach angle/departure angle (°)	18/16
Axle load	1710/2785kg
Front overhang/rear overhang (mm)	1115/1435
Maximum speed (km/h)	110

Chassis Technical Specifications
Type	Diesel
Make/Model	95hp/Euro6
Number of leaf springs	7/5+3, 7/5+2, 3/5+2, 2/3+2
Front track width (mm)	1345
Rear track width (mm)	1292
Engine power	70
Engine displacement	2.3L
