With road cleaning, road cleaning, roadside and roadside stone facade washing and spray dust removal and other functions and novel shape, the vehicle is beautiful.
Gas channel delay technology and suction nozzle, fan blade improvement makes the flow field of the airway optimized, less dust return, more powerful fan, more reliable suction nozzle.
The dustbin is made of 4 mm thick single-layer stainless steel tile structure (national patent), with an effective volume of 2.8 cubic meters. The design not only makes the appearance novel, but also enhances the strength and stiffness of the dustbin and reduces the self-weight.
Combined high pressure cleaning spray rod (national patent) by the high pressure cleaning spray rod is composed of left and right spray rod and nozzle spray rod, the height of the spray rod is fixed from the ground during operation, does not change with the load of the vehicle, can achieve and stabilize the best cleaning effect.
All casting parts, sweep arm double cylinder design, structural optimization and lightweight design technology to ensure the overall optimization of the cleaning system, higher efficiency, longer life, optimal strength.
Equipped with patented technology, one-button intelligent electric control system and auxiliary speed control device.
| Truck Model: | BJ5123TXSEV-P1 |
| Total Mass: | 12490 kg |
| Rated Load: | N/A |
| Total Volume of Clean Water Tank: | 8.5 m3 |
| Total Volume of Dustbin: | 7 m3 |
| Braking Distance: | ??10 m |
| Basic Turck(L * W * H): | 7440 mm * 2370 mm * 2600 mm |
| Min.Turning Diameter: | 18 m |
| Max.Driving Speed: | 80 km/h |
| Sweeping Width: | 3.5 m |
| Max.Cleaning Width: | 3.1 m |
| Cleaning Speed: | 3-20 km/h |
| Lead Time: | 15-30 Working Days |
| Payment Terms: | T/T ,L/C |
Foton BJ5123TXSEV-P1 Road Cleaning and Sweeping Truck Data Sheet | |||||
| Model | BJ5123TXSEV-P1 | Min.Ground Clearance | 190 mm | ||
| Total Mass | 1249 kg | Equipment Weight | 9500 kg | ||
| Rated Load (kg) | N/A | Truck Length | 7440 mm | Truck Width | 2370 mm |
| Truck Height | 2600 mm | Max. Approach Angle (??) | N/A | Max. Departure Angle (??) | N/A |
Chassis Argument of Foton BJ5123TXSEV-P1 Road Cleaning and Sweeping Truck | |||||
| Model Specifications | BJ1128EVJA1 | Wheelbase | 4200 mm | Max.Driving Speed | 80 km/h |
| Max.Gradeability | 20 ?? | Braking Distance | ??10 m | Min.Turning Diameter | 18 m |
| Motor Model | FTTB080C | Motor Rated / Peak Power | 160 kW / 4500 RPM | ||
| ????END???? | |||||
Foton BJ5123TXSEV-P1 Road Cleaning and Sweeping Truck Cleaning System Parameters | |||||
| Total Volume of Clean WaterTank | 4600 L | Total Volume of Dustbin | 2600 L | ||
| Max.Cleaning Capacity | 62000 ?O/h | Battery Model | 12V-140AH | ||
| Max.Pressure of Cleaning Water | 10 Mpa | The Max.Flow of Cleaning Water | 75 L/min | ||
| High Pressure Water Pump Model | NX-C75/150L | High Pressure Water Pump Rated Pressure | 15 Mpa | ||
| Straw Diameter | 180 mm | Ground Clearance of Rigid Part During Operation | 10 mm ?C 15 mm | ||
| System Operating Pressure | 10 Mpa | Chassis Vehicle System Voltage | 24 V | ||
| Working Device System Voltage | 24 V | Hydraulic System Overflow Pressure | 60 Mpa | ||
| Fan Rated Speed | 2300 RPM | Hydraulic Oil Capacity | 60 L | ||
| Rated Flow | 75 L/min | Rated speed | 1450 RPM | ||
| Cleaning Speed | 3-20 km / h | Fan Motor Power | 37 kW | Water Pump Motor Power | 40 kW |
| Max.Cleaning Width | 3.1 m | Sweeping Width | 3.5 m | Unloading Angle | ??45 ?? |
| ??-END??- | |||||
Optional Accessories of Foton BJ5123TXSEV-P1 Road Cleaning and Sweeping Truck | |||||
| 1. Electric Control 360 | 2. Butter Automatic Compensation System (External Source) | 3. Crushed Leaves | |||
| 4.Low-Pressure Waterway | 5. Atomization System | ||||
| ????END???? | |||||
